    100m Span Preformed Dead End Clamp , Aluminum Clad Steel Preformed Dead End Cable Grips

    Ask Lasest Price
    Brand Name : HC , OEM
    Model Number : ANJ1160 , ANJ1280 , ANJ1410
    Certification : CE , SGS , ISO2018
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 5000 Sets Per day
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    100m Span Preformed Dead End Clamp , Aluminum Clad Steel Preformed Dead End Cable Grips

    Aluminum Clad Steel Preformed Dead End Clamp


    The thension dead-end is a dielectric Dead-end designed to terminate short span, low ension ADSS FIBER Optic cables in low voltage environments. Un-like the limited, medium and high tension one found later in this section, the lite tension dead end is reduced to a sigle layer component that offers an economical solution for every light loads.The products effectively transfer the low anxial load on the cable.


    1,Material of preformed rods- aluminum-clad steel rod or galvanization steel rod.

    2,The Max. span will be 100m.

    1.1 Specification

    ModelAvailable Dia. of Cable

    Length of Dead-end Component


    Weight(kg)Universal Scheme
    ClevisThimble
    ANJ 09509.0-9.58000.38GHX-04TC-04
    ANJ 10509.6-10.58500.49GHX-04TC-04
    ANJ 116010.6-11.69000.52GHX-04TC-04
    ANJ 128011.7-12.89600.65GHX-04TC-04
    ANJ 141012.9-14.110800.82GHX-04TC-04
    ANJ 156014.2-15.611601.22GHX-04TC-04

    3:Packing:Wooden Case , Carton Etc
